Jigsaw Puzzle Die Cutting Press Machine



Jigsaw Puzzle Machine Video

Jigsaw Puzzle Die Cutting Machine

The following are advantages of Jigsaw Puzzle Die Cutting Press

1. Fast speed, high precision, easy operation;
2. With six side protection;
3. Compact and good appearance.
4. Pressure stability,has no phenomenon of cutting and rough edge.Because the cutting is balanced and accurate. which can ensure the using life of cutting board.

5. All lubrication system are provided by the manual pump for lubricating oil,reducing the wear,and extending the using life of the machine.
6. When the cutting operation from hte upper board pressed it can be cut slowly

7. Automatically,which makes no dimension error between them.

8. Optimize structure when designed and do not worry about oil leaks.
9. Make the knife mould set quickly and accuracy,easy to learn.
10. Low motor power and low energy consumption.
11. Equipped with a safety device(according to customer’ requirements.
12. It is suitable for all kinds of materials except for metal to cut and press.

Our servo jigsaw puzzle machine for 1000-3000pcs puzzles, can cut materials such as paper cardboard, plywood and plastic trimming and glue. Edge smooth and closely without burrs. It is widely used for gifts, home decorations and educational toys. It gives great space for your own creations on jigsaw puzzles.

Model		Units	Specifications
			DPT-300	DPT-500	DPT-1000
Main cylinder capacity		Ton	300	500	1000
System pressure		Mpa	240	250	250
Main cylinder stroke		mm	150(185)	150(185)	150
Open height		mm	165(200)	165(200)	170
Height of fixed working table		mm	1099(1114)	1284(1319)	1700
Size of working table	L-R	mm	800	900	1100
	F-B	mm	900	1050	1440
Speeds of main cylinder	Fast forward	mm/s	135	135	110
	Working	mm/s	6	4	43
	Fast backward	mm/s	125	125	100
Over all dimension	L-R	mm	1580	1600	2200
	F-B	mm	1705	1865	1900
	H	mm	1855(1890)	2145(2180)	2930
Main motor power		kw	11	15	30
Weight(Approx)		kg	7600(7800)	9100(9500)	11670
